| Feature | Typical Specification |
|---|---|
| CPU Support / Socket | LGA 1700; supports Intel 12th Gen, 13th Gen, and sometimes 14th Gen CPUs (Core / Pentium Gold / Celeron) |
| Chipset | Intel H610 |
| Form Factor | micro‑ATX / M‑ATX (approx. 200 × 236 mm or similar) |
| Memory / RAM Slots | 2 × DDR4 DIMM slots (dual channel) |
| Maximum RAM Capacity / Speeds | Up to 64 GB DDR4; typical supported speeds include 2133, 2400, 2666, sometimes 3200 MHz (depending on model and CPU) |
| PCIe / Expansion Slots | 1 × PCIe x16 (often PCIe 4.0 from CPU) 1 × PCIe x1 (from chipset) |
| Storage Interfaces | 1 × M.2 slot (usually PCIe 3.0 x4) 2–4 × SATA 6 Gb/s ports |
| Graphics / Display Output | HDMI + VGA (onboard) — usable when CPU has integrated graphics |
| Audio | Realtek ALC897 or ALC892 (7.1‑channel HD audio) |
| LAN / Networking | 1 × Gigabit Ethernet (Realtek RTL8111H or similar) WiFi available only in WiFi variants (not standard models) |
| Rear I/O / USB | USB 3.2 Gen1 ports, USB 2.0 ports, HDMI, VGA, LAN, audio jacks |
| Internal Headers & Features | Fan connectors, TPM header, front panel connectors, debug LEDs in many models |
| Operating System Support | Windows 10 & Windows 11 (64‑bit) |
| Warranty | Typically ~3 years |
